Transmissions
General Motors
|
Type |
Year |
Application |
Shift Pattern |
Low Gear |
Remarks |
Not For
Street Use |
Part# |
| GENERAL MOTORS | x | Case | x | ||||
| Alum. Powerglide | 62-73 | Street | PRN21 | 1.82 | Manual/Automatic | 22601 | |
| Alum. Powerglide | 62-73 | Competition | PRN21 | 1.76 | Manual Only/Steel Clutch Hub/Turbo Spline Input Shaft | 22662 | |
| Alum. Powerglide | 62-73 | Competition | PRN12 | 1.76 | Manual Only/Steel Clutch Hub/Turbo Spline Input Shaft | 22664 | |
| Alum. Powerglide | 62-73 | Competition | PRN21 | 1.82 | Manual Only/Steel Clutch Hub/Turbo Spline Input Shaft | 22673 | |
| Alum. Powerglide | 62-73 | Competition | PRN12 | 1.82 | Manual Only/Steel Clutch Hub/Turbo Spline Input Shaft | 22675 | |
| Alum. Powerglide | 62-73 | Competition | PRN21 | 1.76 | Manual Only/Steel Clutch Hub/PG Spline Input Shaft | 22682 | |
| Alum. Powerglide | 62-73 | Competition | PRN12 | 1.76 | Manual Only/Steel Clutch Hub/PG Spline Input Shaft | 22684 | |
| Alum. Powerglide | 62-73 | Competition | PRN21 | 1.82 | Manual Only/Steel Clutch Hub/PG Spline Input Shaft | 22693 | |
| Alum. Powerglide | 62-73 | Competition | PRN12 | 1.82 | Manual Only/Steel Clutch Hub/PG Spline Input Shaft | 22695 | |
| Alum. Powerglide | 62-73 | Competition Pro Series |
PRN21 | 1.76 | Manual Only/Steel Clutch Hub/Turbo Spline Input Shaft/Tranz Brake | x | 22962 |
| Alum. Powerglide | 62-73 | Competition Pro Series |
PRN12 | 1.76 | Manual Only/Steel Clutch Hub/Turbo Spline Input Shaft/Tranz Brake | x | 22964 |
| Alum. Powerglide | 62-73 | Competition Pro Series |
PRN21 | 1.76 | Manual Only/Steel Clutch Hub/PG Spline Input Shaft/Tranz Brake | x | 22982 |
|
Type |
Year |
Application |
Shift Pattern |
Low Gear |
Remarks |
Not For
Street Use |
Part# |
| TH350, 375B | 69-86 | Street | PRN321 | 2.52 | Manual/ Automatic/Universal Case | 23161CP**+ | |
| TH350, 375B | 69-86 | Street | PRN321 | 2.75 | Manual /Automatic/Universal Case | 23161CPL**+ | |
| TH350, 375B | 69-86 | Pro Street | PRN321 | 2.52 | Manual Only/Universal Case/Full Engine Braking | 23162CP** | |
| TH350, 375B | 69-86 | Pro Street | PRN321 | 2.75 | Manual Only/Universal Case/Full Engine Braking | 23162CPL** | |
| TH350, 375B | 69-86 | Competition | PRN321 | 2.52 | Manual Only/Universal Case/NEB 1st | x | 23163CP** |
| TH350, 375B | 69-86 | Competition | PRN321 | 2.75 | Manual Only/Universal Case/NEB 1st | x | 23163CPL** |
| TH350, 375B | 69-86 | Competition Electronic | PRN321 | 2.52 | E-Shift/Universal Case/NEB 1st |
x |
23163CPE** |
|
Type |
Year |
Application |
Shift Pattern |
Low Gear |
Remarks | Not For
Street Use |
Part# |
| TH400, 375 | 65-87 | Street | PRN321 | 2.48 | Manual/Automatic/Chevy Case/Spec Intermediate Sprag | 24241C**+ | |
| TH400, 375 | 65-87 | Street Hi Performance |
PRN321 | 2.48 | Manual/Automatic/Chevy Case/Spec Intermediate Sprag/4-Intermediate Clutches/6-Direct Clutches | 24241CHP**+ | |
| TH400, 375 | 65-87 | Street | PRN321 | 2.48 | Manual/Automatic/POB Case/Spec Intermediate Sprag | 24241P**+ | |
| TH400, 375 | 65-87 | Street Hi Performance |
PRN321 | 2.48 | Manual/Automatic/POB Case/Spec Intermediate Sprag/4-Intermediate Clutches/6-Direct Clutches | 24241PHP**+ | |
| TH400, 375 | 65-87 | Competition | PRN123 | 2.48 | Manual Only/Chevy Case/Spec Intermediate Sprag/NEB 1st & 2nd | x | 24242C** |
| TH400, 375 | 65-87 | Competition | PRN123 | 2.48 | Manual Only/Chevy Case/Spec Intermediate Sprag/NEB 1st & 2nd/4-Intermediate Clutches/6-Direct Clutches |
x |
24242CHP** |
| TH400, 375 | 65-87 | Competition | PRN123 | 2.48 | Manual
Only/POB Case/Spec Intermediate Sprag
NEB 1st & 2nd |
x | 24242P** |
| TH400, 375 | 65-87 | Competition | PRN123 | 2.48 | Manual Only/Chevy Case/Spec Intermediate Sprag/NEB 1st & 2nd/4-Intermediate Clutches/6-Direct Clutches |
x |
24242PHP** |
| TH400, 375 | 65-87 | Competition Pro Street | PRN321 | 2.48 | Manual Only/Chevy Case/Spec Intermediate Sprag/Full Engine Braking | 24243C** | |
| TH400, 375 | 65-87 | Competition Pro Street Hi Performance |
PRN321 | 2.48 | Manual Only/POB Case/Spec Intermediate Sprag/Full Engine Braking/4-Intermediate Clutches/6-Direct Clutches | 24243CHP** | |
| TH400, 375 | 65-87 | Competition Pro Street Hi Performance |
PRN321 | 2.48 | Manual Only/POB Case/Spec Intermediate Sprag/Full Engine Braking | 24243P** | |
| TH400, 375 | 65-87 | Competition Pro Series |
PRN123 | 2.48 | Manual Only/Chevy Case/Spec Intermediate Sprag/NEB 1st & 2nd/Tranz Brake | x | 24942** |
| TH400, 375 | 65-87 | Competition Pro Series Hi Performance |
PRN123 | 2.48 | Manual Only/Chevy Case/Spec Intermediate Sprag/NEB 1st & 2nd/Tranz Brake/4-Intermediate Clutches/6-Direct Clutches |
x |
24942HP** |
| TH400, 375 | 65-87 | Competition Pro Series |
PRN123 | 2.48 | Manual Only/POB Case/Spec Intermediate Sprag/NEB 1st & 2nd/Tranz Brake | x | 24945** |
| TH400, 375 | 65-87 | Competition Pro Series Hi Performance |
PRN123 | 2.48 | Manual Only/POB Case/Spec Intermediate Sprag/NEB 1st & 2nd/Tranz Brake/4-Intermediate Clutches/6-Direct Clutches |
x |
24945HP* |
|
Type |
Year |
Application |
Shift Pattern |
Low Gear |
Remarks |
Not For Street Use |
Part# |
| TH200 | Street | PRN321 | 2.74 | Manual/Automatic Chevy Case | 27161C* | ||
| TH200 | Street | PRN321 | 2.74 | Manual/Automatic POB Case | 27161P* | ||
| TH200 | Competition | PRN321 | 2.74 | Manual Only Chevy Case NEB 1st |
x |
27163C | |
| TH200 | Competition | PRN321 | 2.74 | Manual Only Chevy Case NEB 1st |
x |
27163CRD | |
| TH200 | Competition | PRN321 | 2.74 | Manual Only POB Case NEB 1st |
x |
27163PRD | |
| TH200 | Competition Electronic | PRN321 | 2.74 | E-SHIFT Chevy Case NEB 1st |
x |
27163CE2RD | |
| TH200 | Competition Electronic | PRN321 | 2.74 | E-SHIFT POB Case NEB 1st |
x |
27163PE2RD |
|
Special Applications Available Upon Request. ** Length of Tail Shaft Housing Required. + Requires Vacuum Modulator Hook-Up. *Requires Passing Gear Linkage Hook up & Properly Functioning x If Bolt on Yoke Required, Add BY to Part Number and Note Additional Charge. Note: All Competition Powerglide Transmissions are Equipped with Part #70040 Multi-Use PG Selector Shaft Kit.
|
